Test Results
screen
In addition to the various parameters, the Test Setup screen also contains
the Application toolbar and the navigation tabs for horizontal and vertical
navigation.
The Test Results screen is the last screen in the workspace. It generally
contains several pages, reflecting the progress of the test. Navigation
buttons at the top of the screen will allow you to switch between the pages
and between ports (when relevant).
In addition to the results, whose presentation varies from application to
application, the Test results screen also contains the Application toolbar
and the navigation tabs for horizontal and vertical navigation.
4.1.4 Lamp Indication of Alarm/Error Status
Alarm and error status is indicated by colored Lamp icons. The following
colors are used:
Red Lamp icon indicates that an alarm has appeared.
Yellow Lamp icon indicates that an error has appeared.
Green Lamp icon indicates a 'no trouble' situation.
