6.1.4.3 Ethernet WAN
When Port is set to SFP+ 10 Gbps WAN, inserting the WAN alarms/errors is
available.
1. Select Alarms or Errors/Violations using the radio button.
2. Select Destination using the drop down menu.
3. Select the Insertion in case of Errors/Violations.
Alarms will be inserted continuously.
Off: Turns off inserting errors.
Manual: Inserts errors in the specified counts if you touch the
Error Insert icon.
4. Touch the WAN burst length field to set the errors insertion counts.
5. When Insertion is set to Manual, Touch the Error Insert icon.
6.1.4.4 Ethernet frequency
Touch the field to set Ethernet frequency. Enter the desired deviation in
the Tx Deviation field. A positive value increases the frequency.
6.2 BERT
