Total Frame
Difference
Ethernet
Please refer to the sections relevant for your current port setup
requirements.
6.8.2 Test Setup
6.8.2.1 Control
Refer to "Control in BERT Test Setup subsection for the operation.
6.8.2.2 Thresholds
Touching the Thresholds button in the navigation area displays the
following screen.
The Follow button appears when the Port 2 settings can follow Port 1.
This screen allows you to set up a number of special monitoring items
related to the various interface types. When specified and enabled, these
threshold values (i.e. limits) for errors and Pass/Fail status will be used during
the monitoring.
Allows you to select the reference port to measure the differential time, using
Difference from: drop down menu.
When you select the check box, you can enable various thresholds. Touch
the Setup button to display the same Ethernet threshold setup dialog
box as BERT.
