This screen presents the results from the Throughput test.
The most important columns of the tables are the varied main parameters
Frame size and Throughput and the performance parameter Frames lost.
The order of the tables will vary depending on the test mode and the relation of
the ports.
Test Mode Port 1 Port 2
Switch/Router test
Port 1 Tx
Port 2 Rx
Port 2 Tx
Port 1 Rx
End to End test
Port 1 Tx
Port 1 Rx
Port 2 Tx
Port 2 Rx
Router latency test
Single ended network test
6.9.3.3 Frame loss
Only available if you have specified a Frame loss test on the 'Control' of the Test
Setup screen.
Touching the Frame loss button in the navigation area will display the
screen shown below.
This screen presents the results from the Frame loss test.
