6.1.4.2 Ethernet PCS alarms/errors
When Port is set to SFP+ 10 Gbps LAN, the PCS alarms/errors is available in
following applications.
BERT
Mon.Gen.
Ch Stat
1. Select Alarms or Errors using the radio button.
2. Select the Destination inserting the alarm or the error.
3. Select the Insertion.
Off: Turns off inserting errors.
Manual: Inserts errors in the specified counts if you touch the
Error Insert icon.
Burst: Inserts errors or alarms in counts you have specified.
Rate: Inserts errors in the specified rate continuously.
Alternate: Repeats error/alarm insertion per specified number of
frames.
All: Inserts errors to all Ethernet frames.
