Combination of Ql Type and Ql
G.781
option I
G.781
option II
G.781
option III
G.8264
QL-INV0 QL-STU QL-UNK QL-INV0
QL-INV1 QL-PRS QL-INV1 QL-INV1
QL-PRC QL-INV2 QL-INV2 QL-INV2
QL-INV3 QL-INV3 QL-INV3 QL-INV3
QL-SSU-A QL-TNC QL-INV4 QL-INV4
QL-INV5 QL-INV5 QL-INV5 QL-INV5
QL-INV6 QL-INV6 QL-INV6 QL-INV6
QL-INV7 QL-ST2 QL-INV7 QL-INV7
QL-SSU-B QL-INV8 QL-INV8 QL-INV8
QL-INV9 QL-INV9 QL-INV9 QL-INV9
QL-INV10 QL-ST3 QL-INV10 QL-EEC2
QL-SEC QL-INV11 QL-SEC QL-EEC1
QL-INV12 QL-SMC QL-INV12 QL-INV12
QL-INV13 QL-ST3E QL-INV13 QL-INV13
QL-INV14 QL-PROV QL-INV14 QL-INV14
QL-DNU QL-DUS QL-INV15 QL-INV15
Src MAC
Allows you to specify the MAC address to be used in ESMC messages. You
can either use the Default check box to force an instrument-specific default
value, or touch the address field to enter an address yourself.
Capture
Selecting this check box enables recording of ESMC messages. The
captured packet data are saved to file with extension "pcap" when the
measurement has ended. The destination folder of the captured data file is
the same folder where the measurement result file is saved.
6.1.2.6 IEEE 1588v2
Touching the IEEE 1588v2 button in the navigation area will display the
screen shown below.
The Follow button appears when the Port 2 settings can follow Port 1.
