Miscellaneous
Throughput
Calculation Layer
Selection
Throughput Type
Graphical
presentation
Use local source addresses for destination on remote side
When this function is enabled, the Network Master does not use the IP or MAC
addresses for differentiating frames during the RFC 2544 test. An exception
is End to End test control, but routing equipment in the network may need
the addresses to be set up correctly. To limit the amount of needed setups
on the Remote side, this setting can be enabled to transfer the source
address setup from the Local using it as destination on the Remote.
However, the source addresses must still be correctly setup on the remote
in order to make the End to End test work.
Store test results on remote side
When this function is enabled, test results will be stored on the remote
instrument.
Include addresses in frame filter on receiver
The receiver uses a filter to determine which frames should be counted in
the results. When this function is enabled, the receiver will use the MAC
addresses of each incoming frame in addition to the 'filter key' used by
default.
Measure jitter by means of latency test
When selected the Latency Test will measure jitter instead of latency.
Accumulate repeated steps
When this function is enabled, repeated steps are accumulated into one
result line.
Select the layer on which the throughput calculation is done. As described in
the Throughput calculation section there are 6 different layers:
Utilization layer throughput
Physical layer throughput
Physical layer throughput (without preamble)
Link layer throughput
Network layer throughput
Data layer throughput
Data layer throughput appears when UDP or TCP is set to the layer 4 of
the Ethernet frame on 'Ports Setup' screen.
Select whether to register Average throughput or Maximum
throughput.
6.9.3 Test Results
The results of the performed RFC 2544 tests can be presented in either
tabular form or as graphical representations. The graphical presentation
mode provides an overview of the results and the progress of the test.
