Selecting type of
results
Studying a
specific result
Selecting
notation
If you have stopped measurement during the interval time, the measurement
results of the current interval are discarded. The log of the current interval is not
displayed in Back field.
In this case, result data are re-calculated excluding the data of the current
interval when the measurement is stopped. This causes that "Count" and "Ratio"
displayed after the measurement will be different from that of during
measurement.
The sum of interval time (multiplied interval time by the number of back logs)
may not match the differential time between displayed time at left top and right
top after the measurement.
Open the middle drop-down menu in the top row of buttons to select which
results you want displayed on the screen.
Performance
Frame
Burst
Size Distribution
Transmit
Multi Stream Transmit
Multi Stream Throughput
Multi Stream Frame Loss
Multi Stream Latency
Multi Stream Jitter
SyncE
IEEE 1588v2
802.3ah
802.1ag/Y.1731
Touch a specific cell in a result table to zoom in on the corresponding result
item. The Count and Ratio fields are displayed on a Zoom tab page. A
Time vs. Statistics tab page is also available. Use the Back button or
touch the zoom filed to return to the statistics screen.
Selecting how results are displayed
Select the required notation for the results from the notation drop-down
menu.
Unformatted - e.g. 71892
SI prefix - e.g. 71.892 k (k means "kilo")
Engineering - e.g. 71.892E3
Scientific - e.g. 7.1892E4
Results
Results are displayed according to your choice.
Performance
Utilization
Throughput
Frame rate
Frame
Alarms
Good Frames
Errored Frames
Other Frames
Last Received
Frame diff.
Bursts
Frames
Burst Size
Size Distribution
Total Frames
Size Dist.
Frame Size
Transmit
Traffic
