PSI
Bits 1-4 Meaning
0000 NR (No request)
0001 DNR (Do not revert)
0010 RR (Reverse request)
0011 Reserved
0100 EXER (Exercise)
0101 Reserved
0110 WT (Wait-to-restore)
0111 Reserved
1000 MS (Manual switch)
1001 Reserved
1010 SD (Signal degrade)
1011 Reserved
1100 SF (Signal fail)
1101 Reserved
1110 FS (Forced switch)
1111 Lockout
PSI means Protocol Structure Identifier. This field shows the payload type. You
can either enter a new value directly in the field or select the relevant value
from the PSI[0] drop-down menu.
