Performance
Parameters
Stop button.
Stop at: Stops the measurement at the time specified in the Stop at
field on the right.
Duration: Performs the measurement for the duration of time specified
on the right.
Memory allocation
Allows you to specify how the measurement will be stored in the Network
Master's memory. Select the relevant option from the drop-down menu:
Use all storage: When Network Master's memory becames full of
measured data, the whole measurement is stopped.
Continuous: When Network Master's memory becames full of
measured data, the oldest records in that memory will be overwritten.
The Network Master's memory size (the file size of measurement results) is
64 Mbytes per one port.
Estimate of test duration
Contains an estimation of the time (in days, hours, minutes and seconds)
before the whole memory will be filled out by the test. During an ongoing
measurement, the estimate will be recalculated periodically.
OTN
Select the ITU-T Recommendation applying to the test.
G.8201 Error performance parameters and objectives for multi-operator
international paths within the Optical Transport Network (OTN)
M.2401 (M.2110)
M.2401 Error performance limits and procedures for bringing-into-
service and maintenance of multi-operator international paths and
sections within an optical transport network
M.2110 Bringing into service international multi-operator paths, sections
and transmission systems
Time period
This parameter is displayed if OTN is set to M.2401(M.2110).
15 minutes, 1 hour, 2 hours, 24 hours, 7 days
Allocation
Touching the Setup button launches the dialog box shown below.
The dialog box is used to set up various performance parameters.
Type
Select the performance type as either G.8201 or M.2401/M.2110. The
contents of the dialog box depends on the selected performance type.
Allocation
