Return Loss
Jitter generation
Jitter Tolerance
Rx Bit Rate
counter
Battery operating
time
Temperature and
Humidity range
Laser Safety
EMC
LVD
2M to 139/45/156M Input
Bit Rate Refer to Bit Rate.
Code/Interface 2.048,34.368 Mbit/s HDB3, BNC 75 Ω
(Balance) 44.736 Mbits/s B3ZS, BNC 75 Ω
139.264,155.52 Mbits/s CMI, BNC 75 Ω
Sensitivity
(2.048Mbit/s)
TERMINATE:
Up to 40 dB cable attenuation, nominal impedance
MONITOR:
20 dB to 26 dB linear attenuation and up to 6 dB cable
attenuation, nominal impedance
20 dB to 30 dB linear attenuation, 0 dB cable attenuation,
nominal impedance
BRIDGED:
Up to 40 dB cable attenuation, high impedance
Sensitivity
(34.368/44.736Mbit/s)
TERMINATE:
Up to 12.0 dB cable attenuation, nominal impedance
MONITOR:
20 dB linear attenuation and up to 12 dB cable
attenuation, nominal impedance
20 dB to 30 dB linear attenuation , 0 dB cable
attenuation, nominal impedance
Sensitivity
(139.264/155.52Mbit/s)
TERMINATE:
Up to 12.0 dB cable attenuation, nominal impedance
MONITOR:
20 dB linear attenuation and up to 12 dB cable
attenuation, nominal impedance
10/100 /1000M Input
Bit Rate Refer to Bit Rate.
Code/Interface
RJ-45
IEEE802.3-2008 10BASE-T, 100BASE-TX, 1000BASE-T compliant
ITU-T G.703 compliant
Optical interface: ITU-T G.783 compliant
Electrical interface: ITU-T G.823, ANSI T1.403, ANSI T1.404 compliant
Optical interface: ITU-T G.825, ITU-T G.8251 compliant
Electrical interface: ITU-T G.823, ITU-T G.824 compliant
Bit Rate Refer to Bit Rate.
Accuracy According to the Internal Clock of MT1000A.
11.2.3 Environment Performance
Operating time: 4 hours (Typ.)
25°C, Depending on operating condition
Operating:0°C to +50°C, ≤85%RH (non-condensing)
Storage:
-30°C to +60°C, ≤90%RH (Excluding battery
and AC adapter)
-20°C to +50°C, ≤90%RH (Including battery and
AC adapter)
(non-condensing)
IEC 60825-1:2007 Class 1
FDA 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser
Notice No.50, dated 2007-June-24.
EN61326-1 and EN61000-3-2.
EN61010-1.
11.2.4 Mechanical Performance
