Cable test
Transmitter Clock
Frequency
deviation
measurement
Frequency Offset
SyncE
functionality
IEEE 1588v2
functionality
11.3 Measurement functionality
11.3.1 Ethernet Measurements
Identifies failures on electrical cables like short-circuits or breaks of a wire
pair and indicates the distance from the instrument to the fault.
Reference Clock
Internal clock
External clock
BITS
SETS
2MHz
10MHz
GPS
Received clock
IEEE1588v2
Refer to Bit Rate
±100 ppm 1 ppm step
Specify quality level (QL) of the transmitted Ethernet signal.
SyncE functionality is available when the interface bit rate is 10Gbps or less.
Analysis of QL indicated in received Ethernet signal. An alarm is raised on
missing QL indications.
SyncE results
SSM Rx count and rate
SSM Tx count
Indicated QL statistics
SSF seconds
ESMC messages capture
ESMC messages can be captured and exported in a Wireshark
compatible format.
Timing master/slave
Each port of the Ethernet interface can act as a timing master or a timing
slave independently.
Supported modes: Multicast (native PTP) and Unicast (G.8265.1). When acting
as master in Unicast (G.8265.1) mode, one slave is accepted at a time, other
slaves are ignored. If the slave requires 32, 64 or 128 Sync messages per
second, the IEEE 1588-2008 paragraph 7.7.2.1 concerning 90% confidence
interval is not followed.
Configurable parameters (per port):
Clock identity
Port number
Priority 1
Priority 2
Domain number
Clock class
Slave only mode
Time source
Encapsulation
Announce receipt timeout
Clock accuracy
Clock step mode
Announce interval
Sync interval
