Traceroute
Ethernet OAM
option
VLAN
Ethernet MPLS
Ethernet
Multistream
Trace the IP route over the IP network.
User-defined max no. of hops (1 to 255)
Information per hop: Maximum/Minimum/Average ping time and number of
ping timeouts
Y.1731 (Service Layer OAM)
IEEE 802.1ag (Connectivity layer OAM) and IEEE 802.3ah (Access Link
OAM)
Number of VLAN tag
Up to 8 layers of VLAN can be inserted into the Ethernet frame.
Only 1 level of VLAN is supported in ping, Traceroute and RFC2544 router
latency tests.
Parameters per VLAN tag
EtherType 0x8100 (802.1Q), 0x88a8 (802.1ad), 0x9100 or 0x9200
User-defined VLAN ID, CFI and VLAN priority
Status
Indicator for detection of VLAN tagged frames
Statistics
Number of VLAN tagged frames
Maximum number of VLAN layers detected
MPLS supported
MPLS unicast is supported (EtherType 0x8847).
Support for MPLS in BERT, RFC 2544 (excluding router latency) tests and
general statistics
Number of MPLS headers
Up to 8 MPLS headers can be set by the user.
Parameters per MPLS header
User-defined label, Exp and TTL fields in each MPLS header
MPLS-TP support
PWE (Pseudo Wire Emulation Edge-to-Edge) label (the RFC4448 control
word) can be added.
Status
Indicator for detection of MPLS frames and MPLS-TP
Statistics
Number of MPLS frames and MPLS-TP frames
Maximum number of MPLS layers detected
Number of streams
Up to 16 streams can be activated on the Ethernet line.
Parameters per stream
Encapsulation (frame format)
Line rate traffic load, up to full line rate
Configurable IP and Ethernet source and destination addresses
(supports IPv4 and IPv6 addressing)
User-defined traffic mix of unicast and broadcast frames
Adjustable frame size from 44 bytes to 16000 bytes
Frame sizes may be set to constant, stepped or random length.
User programmable VLAN ID and VLAN priority
User programmable DSCP/TOS byte
