SONET Mappings
Dummy channel
handling
Test patterns
Preset data
Tandem
connection
Frequency Offset
Alarm Insertion
Error Insertion
OC-192 - STS-192c - STS-192c SPE - Bulk
OC-192/OC-48 - STS-48c - STS-48c SPE - Bulk
OC-192/OC-48/OC-12 - STS-12c - STS-12c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - E4
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - DS1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-11 - VT-11 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-11 - VT-11 SPE - DS1/J1 (Async/Sync)
Copy, Unequipped (For STS only)
PRBS: 2
9
-1, 2
11
-1, 2
15
-1, 2
20
-1, 2
23
-1, 2
29
-1,2
31
-1 (Normal/Inverse)
Fixed :User Pattern, All0, All1, Alternating 1:1, Alternating 1:3, Alternating
1:7, 2 in 8
User Pattern : 32 bit, 2048 bit
OH Preset data
TOH : All bytes except B1, B2, H1, H2 and H3 byte
STS-3c/STS-1 POH : All bytes except B3
VT-2/VT-1.5 POH : All bytes except BIP-2
Path trace Setting: J0, J1, J2 (Ascii data, 16 bytes/64 bytes)
Off, Z5(STS-3c), Z5(STS-1), Z6(VT-2), Z6(VT-1.5)
±50 ppm 1 ppm step
Item
LOS, LOF, OOF, AIS-L, RDI-L, AIS-P, LOP-P, TIM-P, PLM-P, UNEQ-P, RDI-P,
AIS-V, LOP-V, LOM-V, TIM-V, UNEQ-V, RDI-V, PLM-V, LSS, TC-UNEQ, TC-LTC,
TC-TIM, TC-AIS, TC-RDI, TC-ODI
Insertion :
Permanent, Alternate (Excluding LOS, OOF and LSS)
Permanent (For LOS, OOF and LSS)
Alternate :
Alarm length : 1 to 8000 (Frame)
Normal length : 1 to 8000 (Frame)
Item
A1A2, B1, B2, REI-L, B3, REI-P, V5/B3, REI-V, TC-IEC, TC-REI, TC-OEI, TC-BIP-
2, ERR-TRANS, Pattern error
Specifications Measurement functionality
