Chapter 14. Appendix
Added functions
Description User's Manual Reference User's Manual Change
Added AI (Analog Input) range types
Chapter 13. Specifications
Input types and ranges (p.13-12)
Added PLII, PR40-20, and N to
thermocouple
Added −10 to +10 V to Linear
Added the advanced loop type setting
option for [Loop type]
4 - 1 Loop Types (p.4-1)
Model numbers and loop types (p.4-1)
Setting the loop type (p.4-4)
Added a description of advanced
loop type setting to “Handling
Precautions”
4-22 Advanced Loop Type Setting
Loop types (p.4-121)
Input assignment (p.4-121)
Virtual AI (analog Input) (p.4-123)
Added the content at left
6 - 2 Parameter Setting Display Data
Input assignment bank (p.6-42)
Virtual analog input bank (p.6-44)
Added the content at left
Chapter 11
Block alarm (p.11-3)
Added the PV and RSP alarms for
loops to the MAIN block alarm
14 - 2 Standard Bit Codes and
Standard Numerical Codes
Standard numerical codes (p.14-8)
Added Virtual AI to 1 to 4, Virtual
PV 1 to 4
Support for the DI (Digital Input) block
4 - 8 DI (Digital Input)
Function block diagram
Added a description of the DI
block
5 - 1 Monitor Screen and Graph
Screen
DI monitor screen (p.5-39)
Added the content at left
14 - 2 Standard Bit Codes and
Standard Numerical Codes
Standard bit codes (p.14-6)
Added DI1 to DI4 terminal status
(blocks A3 and B3)
Chapter 11
Block alarm (p.11-3)
Added the block alarm for DI
(slots A3 and B3)
Support for the DO (digital output) block
4 - 10 DO (Digital Output) (p.4-65)
Function block diagram
Added a description of the DO
block
5 - 1 Monitor Screen and Graph Screen
DO monitor screen (p.5-40)
Added the content at left
6 - 2 Parameter Setting Display Data
DO configuration bank (p.6-20)
Added the content at left
14 - 2 Standard Bit Codes and
Standard Numerical Codes
Standard bit codes (p.14-6)
Added DO1 to DI4 terminal
status (blocks A1 and B1)
Chapter 11
Block alarm (p.11-3)
Added the block alarm for DO
(slots A1 and B1)
