Show Commands
show flow sw-monitor
485
Cisco Nexus 7000 Series NX-OS System Management Command Reference
OL-25806-03
This example shows how to display the status and statistics for the flow monitor named
NFC-DC-PHOENIX in a table format:
switch# show flow sw-monitor NFC-DC-PHOENIX cache format table
Cache type: Normal
Cache size: 4096
Current entries: 4
High Watermark: 6
Flows added: 90
Flows aged: 86
- Active timeout ( 1800 secs) 0
- Inactive timeout ( 15 secs) 86
- Event aged 0
- Watermark aged 0
- Emergency aged 0
IP TOS IP PROT IPV4 SRC ADDR IPV4 DST ADDR TRNS SRC PORT TRNS DST PORT
====== ======= =============== =============== ============= ==============
0x00 1 10.251.10.1 172.16.10.2 0 02
0x00 1 10.251.10.1 172.16.10.2 0 20484
0xC0 17 172.16.6.1 224.0(1).0.9 520 5202
0x00 6 10.10.11.1 172.16.10.5 25 252
switch#
Related Commands
ip source as The BGP source AS number.
ip destination as The BGP destination AS number.
ipv4 next hop address The IPv4 address of the next hop that the packet is forwarded
to.
ipv4 source mask The IPv4 source address mask.
ipv4 destination mask The IPv4 destination address mask.
tcp flags The value of the TCP flags.
interface output The interface that the input is transmitted on.
counter bytes The number of bytes that have been counted.
counter packets The number of packets that have been counted.
timestamp first The timestamp of the first packet in the flow.
timestamp last The timestamp of the last packet in the flow.
Table 4 show flow sw-monitor monitor-name Field Descriptions (continued)
Field Description
Command Description
cache Configures flow cache parameters for flow monitors.
clear flow monitor Clears the flow monitor.
exporter Specifies a flow exporter for flow monitors.
flow monitor Creates a flow monitor.
protocol-distribution Configures the collection of protocol distribution statistics for flow
monitors.
record Configures a flow record for the flow monitor.
