Show Commands
show flow sw-monitor
484
Cisco Nexus 7000 Series NX-OS System Management Command Reference
OL-25806-03
TRNS DESTINATION PORT: 20
INTERFACE INPUT: Et0/0
FLOW SAMPLER ID: 0
ip source as: 0
ip destination as: 0
ipv4 next hop address: 172.16.7.2
ipv4 source mask: /0
ipv4 destination mask: /24
tcp flags: 0x00
interface output: Et1/0
counter bytes: 198520
counter packets: 4963
timestamp first: 10564356
timestamp last: 12154104
Table 4 describes the significant fields shown in the display.
Ta b l e 4 show flow sw-monitor monitor-name Field Descriptions
Field Description
Cache type The flow monitor cache type.
The possible values are as follows:
• Normal—Flows are expired normally
• Permanent—Flows are never expired
• Immediate—Flows are expired immediately
Cache Size The number of entries in the cache.
Current entries The number of entries in the cache that are in use.
High Watermark The highest number of cache entries seen.
Flows added Flows added to the cache since the cache was created.
Flows aged Flows expired from the cache since the cache was created.
Active timeout The current value for the inactive timeout.
Inactive timeout The current value for the active timeout.
Event aged The number of flows that have been aged by an event such as
using the force-export option for the clear flow monitor
command.
Watermark aged The number of flows that have been aged because they
exceeded the maximum high watermark value.
Emergency aged The number of flows that were aged from the cache to allow
new flows to be added.
IP TOS The IP type of service (ToS) value.
IP PROTOCOL The protocol number.
IPV4 SOURCE ADDRESS The IPv4 source address.
IPV4 DESTINATION ADDRESS The IPv4 destination address.
TRNS SOURCE PORT The source port for the transport protocol.
TRNS DESTINATION PORT The destination port for the transport protocol.
INTERFACE INPUT The interface that the input is received on.
FLOW SAMPLER ID The flow sampler ID number.
