DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
194
user_define - (Optional) Specify that the rule applies to the IP protocol ID and the mask
options behind the first 4 bytes of the IP payload.
<hex 0x0-0xffffffff> - Enter the user-defined IP protocol ID mask here.
packet_content - Specify the frame content pattern, there are 5 offsets in maximum could be
configure. Each offset presents 16 bytes, the range of content of frame is 80 bytes(5 offsets)
in the first eighty bytes of frame.
offset_0-15 - (Optional) Specify that the mask pattern offset of the frame will be between 0
and 15.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 0 and 15 here.
offset_16-31 - (Optional) Specify that the mask pattern offset of the frame will be between 16
and 31.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 16 and 31 here.
offset_32-47 - (Optional) Specify that the mask pattern offset of the frame will be between 32
and 47.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 32 and 47 here.
offset_48-63 - (Optional) Specify that the mask pattern offset of the frame will be between 48
and 63.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 48 and 63 here.
offset_64-79 - (Optional) Specify that the mask pattern offset of the frame will be between 64
and 79.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 64 and 79 here.
ipv6 - Specify the rule applies to IPv6 fields.
class - (Optional) Specify the value of IPv6 class.
<value 0-255> - Enter the IPv6 class value here. This value must be between 0 and 255.
flowlabel - (Optional) Specify the value of IPv6 flowlabel.
<hex 0x0-0xffff> - Enter the IPv6 flowlabel here.
source_ipv6 - (Optional) Specify the value of IPv6 source address.
<ipv6addr> - Enter the IPv6 source address used for this configuration here.
destination_ipv6 - (Optional) Specify the value of IPv6 destination address.
<ipv6addr> - Enter the IPv6 destination address used for this configuration here.
port - Specify the list of ports to be included in this configuration.
<portlist> - Enter a list of ports used for the configuration here.
all - Specify that all the ports will be used for this configuration.
permit - Specify the packets that match the access profile are permit by the Switch.
deny - Specify the packets that match the access profile are filtered by the Switch.
time_range - (Optional) Specify name of this time range entry.
<range_name 32> - Enter the time range here.
delete - Specify to delete a rule from the profile ID entered.
access_id - Specify the index of access list entry. The range of this value is 1-100.
<value 1-100> - Enter the access ID here. This value must be between 1 and 100.
Restrictions
Only Administrators and Operators can issue this command.
Example
To configure CPU access list entry:
