SV-EMS-220/221 Installation and Configuration
7-16 SkyView System Installation Guide - Revision AA
Pin
EMS 37-pin
Harness Wire
Color
Function
Sensor Config
1
Red
Voltmeter 1 (0 to 30 volts DC)
V
2
Yellow or Unwired
Voltmeter 2 (0 to 30 volts DC)
V
3
Black
Ground
G
4
Violet/Blue
General Purpose Input 1
A
5
Black
Ground
G
6
White/Yellow
General Purpose Input 11
(Typically used for Fuel Pressure)
B
7
White/Brown
General Purpose Input 12
(Typically used for Oil Temperature)
A
8
Brown
Enhanced General Purpose Input 4
(Typically used for Oil Pressure)
C
9
Brown/Blue
General Purpose Input 5
A
10
Brown/Yellow
General Purpose Input 6
A
11
Orange
General Purpose Input 7
A
12
Yellow
General Purpose Input 8
A
13
Black
Ground
G
14
Yellow
Fuel Flow Input 1
F
15
Red
Auxiliary 12 volt DC Output
O
16
Black
Ground
G
17
Black
Ground
G
18
White/Red
Auxiliary 5 volt DC Output
O
19
White/Black
Fuel Flow Input 2 (Return)
F
20
Orange/Brown
General Purpose Input 9
A
21
Orange/Blue
General Purpose Input 10
A
22
Violet/Yellow
Enhanced General Purpose Input 2
C
23
Violet/Green
Enhanced General Purpose Input 3
C
24
Orange/Green
Amps +
Amps Shunt
25
Orange/Violet
Amps -
Amps Shunt
26
Green/Red
Manifold Pressure Input
Manifold Pressure P/N
100434-000
27
Open
SV-EMS-220: General Purpose TC Input 1+
Thermocouple +
SV-EMS-221: Propeller controller RPM Output
Propeller controller
28
Open
SV-EMS-220: General Purpose TC Input 1-
Thermocouple -
SV-EMS-221: Propeller controller RPM Ground
Propeller controller
29
Yellow/Green
Warning Light
Optional External
Alarm Indicator
30
Black
Ground
G
31
White/Orange
Enhanced General Purpose Input 13
C
