SV-AP-PANEL Installation
18-6 SkyView System Installation Guide - Revision AA
D15M
Pin
Pin Function
Notes
7
MOTOR 1 WIRE #1
Pin 3 or Pin 5 grounded:
Pin 7 polarity is +, Pin 8 polarity is -
(Motor rotates in one direction)
Pin 4 or Pin 6 grounded:
Pin 7 polarity is -, Pin 8 polarity is +
(Motor rotates in the other direction)
8
MOTOR 1 WIRE #2
9
12 Volts @ 4A
If trim motor(s) control is not used, do not connect. Power
and ground for SV-AP-PANEL front panel buttons is
provided by SkyView Network.
10
PILOT TRIM RIGHT
Motor 2: Pin 14 polarity is +, Pin 15 polarity is -
11
PILOT TRIM LEFT
Motor 2: Pin 14 polarity is -, Pin 15 polarity is +
12
COPILOT TRIM RIGHT
Motor 2: Pin 14 polarity is +, Pin 15 polarity is -
13
COPILOT TRIM LEFT
Motor 2: Pin 14 polarity is -, Pin 15 polarity is +
14
MOTOR 2 WIRE #1
Pin 10 or Pin 12 grounded
Pin 14 polarity is +, Pin 15 polarity is -
(Motor rotates in one direction)
Pin 11 or Pin 13 grounded
Pin 14 polarity is -, Pin 15 polarity is +
(Motor rotates in the other direction)
15
MOTOR 2 WIRE #2
Table 98 – SV-AP-PANEL Trim Motor Control Pinout
