Appendix I: SkyView System Installation Guide Revision History
SkyView System Installation Guide - Revision AA 29-9
o Improved: Fuel quantity gauges can now use arc, bar, and contact widget
styles
o Improved: Engine gauge widgets can now be set to the lower of zero or the
lowest possible value defined via the sensor definition file (.sfg).
o Improved: All aviation databases now trigger an OUT OF DATA notice after
their expiration.
o Fixed: Basemaps available as of 5.0 release now sync over Ethernet
connection when loaded onto SkyView systems with 5.0 or later SkyView
software.
o Fixed: Extremely short flight plan legs no longer cause automatic waypoint
sequencing to stop.
o Fixed: User waypoint altitudes now displayed on their INFO pages.
Updated SV-XPNDR-261/262 Installation, Configuration, and Testing section, as well as
relevant appendix data, to reflect updated ADS-B Out capability, improved squat-
switchless air/ground detection and automatic mode switching.
Added basic explanation of EMS voltmeter inputs.
Clarified the boom mount does not incorporate drainage features.
Added link to FAA AIM for further ADS-B and TIS system information.
Clarified SV-XPNDR-261/262 serial port wiring.
Added engine alert inhibit information.
Added voltage measurement capability and ultimate limit for type “C” EMS inputs.
Improved standby network error troubleshooting explanation.
Updated recommendation to have servos powered whenever SkyView is powered on.
Added description of take-off position marking for trim calibrations.
Added SV-ADSB-470 installation information.
Documented move of INHIBIT ENGINE ALERTS AT BOOT option to Engine Information
menu.
Updated return to service appendix.
308 pages
Document number changed to 101320-013
Software changes in SkyView Software 5.1:
o New: User data logging. One user-configurable data log can record virtually
all aspects of SkyView's state at rates between 0.1Hz and 16Hz. A second
non-configurable "recent flight" data log records the last 15 minutes of
flight data at 16 Hz. Both are CSV (comma separated value) files that are
exported to USB.
Exported files are compatible with the free SavvyAnalysis.com engine
analysis tools
o Improved: Stadium TFRs, which do not have FAA-reported active times, are
now a separately de-clutterable item under MAP MENU > MAP ITEMS.
These airspaces are graphically depicted in orange on the map page.
o Updated: EMS and SYSTEM serial outputs formats changed. Third party
products that use the older formats will need to be updated before they will
be compatible with the 5.1 formats. Vertical Power VP-200 system is not yet
compatible with this update (as of Feb. 2013).
o Fixed: Map info items no longer show erroneous data when aircraft is
stationary.
o Fixed: Compass calibration now works reliably when more than one
ADAHRS installed. Previously, some customers have experienced trouble
getting both ADAHRS properly calibrated, leading to cross-check errors.
o Fixed: Map page shows map picture upon initial power up, even if GPS lock
has not yet been achieved.
Updated Serial Data Output Format Specifications. SYSTEM and EMS formats have
changed for Software v5.1.
Documented new internal data logging feature (Appendix F)
Added a note to reinforce that the servo shear screw should NEVER be removed or
adjusted in the normal process of installing an autopilot servo.
312 pages
Document number changed to 101320-014
Software changes in SkyView Software v6.0:
