Ericsson ECN330 - Page 1068

Command Line Interface
1062 1553-KDU 137 365 Uen D 2006-06-16
Example
This example creates a summary address for all area routes in the range of
10.2.x.x.
7.26.25 area default-cost
This command specifies a cost for the default summary route sent into a stub or
not-so-stubby area (NSSA) from an Area Border Router (ABR). Use the no form
to remove the assigned default cost.
Syntax
area <area-id> default-cost <cost>
no area <area-id> default-cost
• area-id - Identifier for a stub or NSSA, in the form of an IP
address.
• cost - Cost for the default summary route sent to a stub or NSSA.
(Range: 0-65535)
Command Mode
Router Configuration
Default Setting
1
Command Usage
• If this command is entered for a normal area, it will changed to a stub.
• If the default cost is set to “0,” the router will not advertise a default route
into the attached stub or NSSA.
Console(config-router)#area 10.2.0.0 range 10.2.0.0 255.255.0.0
advertise
Console(config-router)#
