Configuring the ECN330-switch
1871553-KDU 137 365 Uen D 2006-06-16
CLI – This example shows the connection status for Port 5.
6.7.2 Configuring Interface Connections
The Port Configuration or Trunk Configuration page can be used to enable/
disable an interface, set auto-negotiation and the interface capabilities to
advertise, or manually fix the speed, duplex mode, and flow control for Fast
Ethenet ports.
Command Attributes
• Name – Allows an interface to be labeled. (Range: 1-64 characters)
• Admin – Allows an interface to be manually disabled. An interface can
be disabled due to abnormal behavior (for example, excessive
collisions), and then reenabled after the problem has been resolved. An
interface may also be disabled for security reasons.
• Speed/Duplex – Allows the port speed and duplex mode to be
manually set.
Console#show interfaces status ethernet 1/5
Information of Eth 1/5
Basic information:
Port Type: 100TX
Mac address: 00-30-f1-47-58-46
Configuration:
Port Admin: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full
Broadcast Storm: Enabled
Broadcast Storm Limit: 500 packets/second
Flow Control: Disabled
LACP: Disabled
Port Security: Disabled
Max MAC Count: 0
Port Security Action: None
Port MAC Learning: Enabled
Media Type: None
Current status:
Link Status: Up
Port Operation Status: Up
Operation Speed-duplex: 100full
Flow Control Type: None
Console#
