Configuring the ECN330-switch
152 1553-KDU 137 365 Uen D 2006-06-16
6.5.6.4 Displaying 802.1X Statistics
The ECN330-switch can display statistics for dot1x protocol exchanges for any
port.
Table 12 802.1X Statistics
Parameter Description
Rx EAPOL Start The number of EAPOL Start frames that have been
received by this Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have
been received by this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been
received by this Authenticator in which the frame
type is not recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that
have been received by this Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been
received by this Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other
than Resp/Id frames) that have been received by
this Authenticator.
Rx EAP LenError The number of EAPOL frames that have been
received by this Authenticator in which the Packet
Body Length field is invalid.
Rx Last EAPOLVer The protocol version number carried in the most
recently received EAPOL frame.
Rx Last EAPOLSrc The source MAC address carried in the most
recently received EAPOL frame.
Tx EAPOL Total The number of EAPOL frames of any type that have
been transmitted by this Authenticator.
