Configuring the ECN330-switch
2051553-KDU 137 365 Uen D 2006-06-16
6.7.3.6 Displaying LACP Settings and Status for the Remote Side
The configuration settings and operational state for the remote side of a link
aggregation can be displayed.
Table 15 LACP Neighbor Configuration Information
Field Description
Partner Admin
System ID
LAG partner’s system ID assigned by the user.
Partner Oper
System ID
LAG partner’s system ID assigned by the LACP
protocol.
Partner Admin
Port Number
Current administrative value of the port number for
the protocol Partner.
Partner Oper
Port Number
Operational port number assigned to this
aggregation port by the port’s protocol partner.
Port Admin
Priority
Current administrative value of the port priority for
the protocol partner.
Port Oper
Priority
Priority value assigned to this aggregation port by
the partner.
Admin Key Current administrative value of the Key for the
protocol partner.
Oper Key Current operational value of the Key for the protocol
partner.
Admin State Administrative values of the partner’s state
parameters. (See preceding table.)
Oper State Operational values of the partner’s state
parameters. (See preceding table.)
