Configuring the ECN330-switch
2551553-KDU 137 365 Uen D 2006-06-16
CLI – This displays STA settings for instance 0, followed by settings for each
port. The settings for instance 0 are global settings that apply to the IST
(page 234), the settings for other instances only apply to the local spanning tree.
Console#show spanning-tree mst 0
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode :MSTP
Spanning tree enable/disable :enable
Instance :0
Vlans configuration :1-4094
Priority :32768
Bridge Hello Time (sec.) :2
Bridge Max Age (sec.) :20
Bridge Forward Delay (sec.) :15
Root Hello Time (sec.) :2
Root Max Age (sec.) :20
Root Forward Delay (sec.) :15
Max hops :20
Remaining hops :20
Designated Root :32768.0.0000ABCD0000
Current root port :1
Current root cost :200000
Number of topology changes :1
Last topology changes time (sec.):645
Transmission limit :3
Path Cost Method :long
---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin Status: Enabled
Role: Designate
State: Forwarding
External Admin Path Cost: 100000
Internal Admin Path Cost: 100000
External Oper Path Cost: 100000
Internal Oper Path Cost: 100000
Priority: 128
Designated Cost: 0
Designated Port: 128.1
Designated Root: 32768.0.000012338976
Designated Bridge: 32768.0.000012338976
Fast Forwarding: Disabled
Forward Transitions: 3
Admin Edge Port: Disabled
Oper Edge Port: Disabled
Admin Link Type: Auto
Oper Link Type: Point-to-point
Spanning Tree Status: Enabled
