Configuring the ECN330-switch
2831553-KDU 137 365 Uen D 2006-06-16
6.12.1.6 Displaying Current VLANs
The VLAN Current Table shows the current port members of each VLAN and
whether or not the port supports VLAN tagging. Ports assigned to a large VLAN
group that crosses several switches should use VLAN tagging. However, for a
small port-based VLAN using one or two switches, tagging can be disabled.
Command Attributes (Web)
• VLAN ID – ID of configured VLAN (1-4094).
• Up Time at Creation – Time this VLAN was created (System Up Time).
• Status – Shows how this VLAN was added to the ECN330-switch.
• Dynamic GVRP: Automatically learned through GVRP.
• Permanent: Added as a static entry.
• Egress Ports – Shows all the VLAN port members.
• Untagged Ports – Shows the untagged VLAN port members.
Web – Click VLAN, 802.1Q VLAN, Current Table. Select any ID from the scroll-
down list.
Figure 112 VLAN Current Table
