Configuring the ECN330-switch
2871553-KDU 137 365 Uen D 2006-06-16
6.12.1.8 Adding Static Members to VLANs (VLAN Index)
Use the VLAN Static Table to configure port members for the selected VLAN
index. Assign ports as tagged if they are connected to 802.1Q VLAN compliant
devices, or untagged they are not connected to any VLAN-compliant devices. Or
configure a port as forbidden to prevent the ECN330-switch from automatically
adding it to a VLAN through the GVRP protocol.
Note: The VLAN Static Membership by Port page can also be used to
configure VLAN groups based on the port index (page 289). However, note that
this configuration page can only add ports to a VLAN as tagged members.
Note: VLAN 1 is the default untagged VLAN containing all ports on the
ECN330-switch, and can only be modified by first reassigning the default port
VLAN ID as described under 6.12.1.10 "Configuring VLAN Behavior for
Interfaces" 290.
Command Attributes
• VLAN – ID of configured VLAN (1-4094, no leading zeroes).
• Name – Name of the VLAN (1 to 32 characters).
• Status – Enables or disables the specified VLAN.
• Enable: VLAN is operational.
• Disable: VLAN is suspended; that is, does not pass packets.
VLAN ID: 249
Type: Static
Name: fsavlan
Status: Active
Ports/Port Channels: Eth1/ 1(S) Eth1/ 2(S) Eth1/ 3(S) Eth1/ 4(S) Eth1/ 5(S)
Eth1/ 6(S) Eth1/ 7(S) Eth1/ 8(S) Eth1/ 9(S) Eth1/10(S)
Eth1/11(S) Eth1/12(S) Eth1/13(S) Eth1/14(S) Eth1/15(S)
Eth1/16(S) Eth1/17(S) Eth1/18(S) Eth1/19(S) Eth1/20(S)
Eth1/21(S) Eth1/22(S) Eth1/23(S) Eth1/24(S) Eth1/28(S)
VLAN ID: 4093
Type: Static
Name: intuntag
Status: Active
Ports/Port Channels: Eth1/28(S)
Console#
