Configuring the ECN330-switch
328 1553-KDU 137 365 Uen D 2006-06-16
Web – Click Priority, Traffic Classes. Assign priorities to the traffic classes (that
is, output queues) for the selected interface, then click Apply.
Figure 132 Traffic Classes
CLI – The following example shows how to change the CoS assignments to a
one-to-one mapping.
Note: Mapping specific values for CoS priorities is implemented as an
interface configuration command, but any changes will apply to the all interfaces
on the ECN330-switch.
Console(config)#interface ethernet 1/1
Console(config)#queue cos-map 0 0
Console(config)#queue cos-map 1 1
Console(config)#queue cos-map 2 2
Console(config)#exit
Console#show queue cos-map ethernet 1/1
Information of Eth 1/1
Traffic Class : 0 1 2 3 4 5 6 7
Priority Queue: 0 1 2 3 4 5 6 7
Information of Eth 1/2
CoS Value: 0 1 2 3 4 5 6 7
Priority Queue: 0 1 2 3 4 5 6 7
.
.
.
