Configuring the ECN330-switch
3371553-KDU 137 365 Uen D 2006-06-16
CLI – The following example globally enables IP Precedence service on the
ECN330-switch, maps IP Precedence value 1 to CoS value 0 (on port 1), and
then displays the IP Precedence settings.
Note: Mapping specific values for IP Precedence is implemented as an
interface configuration command, but any changes will apply to the all interfaces
on the ECN330-switch.
Console(config)#map ip precedence
Console(config)#interface ethernet 1/1
Console(config-if)#map ip precedence 1 cos 0
Console(config-if)#end
Console#show map ip precedence ethernet 1/1
Precedence mapping status: disabled
Port Precedence COS
--------- ---------- ---
Eth 1/ 1 0 0
Eth 1/ 1 1 0
Eth 1/ 1 2 2
Eth 1/ 1 3 3
Eth 1/ 1 4 4
Eth 1/ 1 5 5
Eth 1/ 1 6 6
Eth 1/ 1 7 7
Console#
