Configuring the ECN330-switch
4531553-KDU 137 365 Uen D 2006-06-16
Change any of the interface-specific protocol parameters, and then click Apply.
Figure 203 OSPF Interface Configuration - Detailed
CLI - This example configures the interface parameters for VLAN 1.
6.20.10.5 Configuring Virtual Links
All OSPF areas must connect to the backbone. If an area does not have a direct
physical connection to the backbone, a virtual link can be configured that
provides a logical path to the backbone. To connect an isolated area to the
backbone, the logical path can cross a single non-backbone area (that is, transit
area) to reach the backbone. To define this path, an ABR must be configured
that serves as an endpoint connecting the isolated area to the common transit
Console(config)#interface vlan 1
Console(config-if)#ip ospf priority 5
Console(config-if)#ip ospf transmit-delay 6
Console(config-if)#ip ospf retransmit-interval 7
Console(config-if)#ip ospf hello-interval 5
Console(config-if)#ip ospf dead-interval 50
Console(config-if)#ip ospf cost 10
Console(config-if)#ip ospf authentication message-digest
Console(config-if)#ip ospf message-digest-key 1 md5 aiebel
Console#
