Command Line Interface
928 1553-KDU 137 365 Uen D 2006-06-16
Command Usage
• Use the policy-map command to specify a policy map and enter
Policy Map configuration mode. Then use the class command to enter
Policy Map Class configuration mode. And finally, use the set and
police commands to specify the match criteria, where the:
• set command classifies the service that an IP packet will receive.
• police command defines the maximum throughput, burst rate,
and the action that results from a policy violation.
• Currently only one rule may be configured per Class Map, one or more
classes may be assigned to a policy map.
Example
This example creates a policy called “rd_policy,” uses the class command to
specify the previously defined “rd_class,” uses the set command to classify the
service that incoming packets will receive, and then uses the police command
to limit the average bandwidth to 100,000 Kbps, the burst rate to 1522 bytes, and
configure the response to drop any violating packets.
Console(config)#policy-map rd_policy
Console(config-pmap)#class rd_class
Console(config-pmap-c)#set ip dscp 3
Console(config-pmap-c)#police 100000 1522 exceed-action drop
Console(config-pmap-c)#
