5-13-6. SOURCE AUDIO
SOURCE AUDIO 531
CH 1:LOSS
CH 2:LOSS
CH 3:LOSS
CH 4:LOSS
SOURCE AUDIO 532
CH 5:LOSS
CH 6:LOSS
CH 7:LOSS
CH 8:LOSS
SOURCE AUDIO 533
CH 9:LOSS
CH10:LOSS
CH11:LOSS
CH12:LOSS
SOURCE AUDIO 534
CH13:LOSS
CH14:LOSS
CH15:LOSS
CH16:LOSS
Parameter Display Description
CH1-CH16
LOSS
PCM
PCM 48kHz
PCM 44.1kHz
PCM 32kHz
PCM Other
SILENCE
SILENCE 48kHz
SILENCE 44.1kHz
SILENCE 32kHz
SILENCE Other
NON-PCM
PCM(Async)
SILENCE (Async)
NON-PCM(Async)
IN (Analog)
UNKNOWN
Displays the status of audio sources CH1 through CH16 that
are selected in the AUDIO MAPPING (MAPPING) menu
(6-5).
LOSS: No audio signals
PCM: Normal audio signal (SDI input)
PCM 48kHz: Normal audio signal (AES input approx. 48kHz)
PCM 44.1kHz: Normal audio signal (AES input approx.
44.1kHz)
PCM 32kHz: Normal audio signal (AES input approx. 32kHz)
PCM Other: Normal audio signal (Other AES input)
SILENCE: Mute signal (SDI input)
SILENCE 48kHz: Mute signal (AES input approx. 48kHz)
SILENCE 44.1kHz: Mute signal (AES input approx. 44.1kHz)
SILENCE 32kHz: Mute signal (AES input approx. 32kHz)
SILENCE Other: Mute signal (Other AES input)
NON-PCM: Compressed audio data such as AC3
PCM (Async) : Normal audio signal (Asynchronous SDI
input)
SILENCE (Async): Mute signal (Asynchronous SDI input)
NON-PCM (Async): Compressed audio data such as AC3
(Asynchronous SDI input)
IN (ANALOG): Analog audio signal
UNKNOWN: Unidentifiable
Displays the status of the selected audio sources CH1 through CH16 that are selected by
MAPPING.
Menu button
STATUS
OTHER
