FOR-A FA-9500 - 6-1-2. SDI REMAPPING

98
6-1-2. SDI REMAPPING
SDI REMAPPING 122
CH SEL:CH1
ASSIGN:SOURCE1
SOURCE:SDI1
Parameter Default Setting range Description
CH SEL CH1 CH1 - CH16
Selects an embedded audio channel
of an SDI output signal from CH1
through 16.
ASSIGN Each SOURCE
SOURCE 1 – 16
*1
500Hz
1KHz
SILENCE
DOWNMIX-L
*2
DOWNMIX-R
*2
Dolby DEC 1 – 8
*3
,
*6
Dolby DM-L
*4
,
*6
Dolby DM-R
*4
,
*6
Dolby ENC 1 – 2
*5
,
*7
Selects an audio signal to assign to
the channel selected under CH SEL.
SOURCE 1-16: Assigned SOURCE
channel signals
500Hz/1KHz: Test signal
SILENCE: Mute signal
DOWNMIX-L/R: Signal generated
by downmixing SOURCE channel
signals.
Dolby DEC 1-8: Dolby-decoded
PCM signals
Dolby DM-L/R: Signal generated by
downmixing Dolby-decoded PCM
signal
Dolby ENC 1-2: Encoded Dolby E
data of selected SOURCE channel
signals.
SOURCE -
SDI1 - 16
AES1 - 8
ANA1 - 4
Displays the input signal in the
SOURCE selected under ASSIGN.
Unvisible if ASSIGN is not set to any
SOURCE 1-16.
*1 See section 6-5 “AUDIO MAPPING (MAPPING)” for details on SOURCE settings.
*2 See section 6-7 “DOWN MIX SET” for details on DOWN MIX settings.
*3 See section 6-9-2 “Dolby DECODER INPUT“ for details on Dolby DEC settings.
*4 See section 6-9-4 “Dolby DOWNMIX“ for details on Dolby DM settings.
*5 See sections 6-9-6 “Dolby ENCODER INPUT“ and 6-9-7 “Dolby ENCODER SETTING“ for
details on Dolby ENC settings.
*6 Not shown if the FA-95D-D option is not installed.
*7 Not shown if the FA-95DE-E option is not installed.
 Auto Channel Pairing for NON-PCM Audio Inputs
The FA-9500 recognizes NON-PCM audio input signals in L/R channel pair units, and adjusts
assignments according to the signal selected for the L channel.
L/R channel pairs are SOURCE 1/2, SOURCE 3/4......SOURCE 15/16.
The channel assignments that are changed by the adjustment will be shown with “＊” as
“CH1:＊SOURCE2”.
Menu button
PROCESS
SDI AUDIO
