6-5. AUDIO MAPPING (MAPPING)
Allows you to route 16 audio channels.
The SOURCE/SRC SET menu allows you to select 16-channel audio signals to process from
among SDI embedded, AES and analog input audio signals.
6-5-1. SOURCE/SRC SEL
SOURCE/SRC SEL 155
SOURCE SEL:CH 1/2
SOURCE SET:SDI 1/2
SRC MODE :AUTO
Parameter Default Setting range Description
SOURCE SEL CH1/2 CH1/2 - CH15/16
Selects stereo pairs of 16-channel
audio signals to be internally
processed.
SOURCE SET
SDI channels
corresponding to
source channels
SDI1/2 - 15/16
*1
AES1/2 - 7/8
*2
ANA1/2 - 3/4
Selects audio signals to input to the
SOURCE that are selected under
SOURCE SEL.
SRC MODE AUTO
AUTO
BY-PASS
SRC IN
Sets the SRC circuit to pass or
by-pass audio signals per channel
pair.
AUTO:
Sets the SRC circuit to pass signals.
However, NON-PCM audio signals
will be by-passed.
BY-PASS:
Sets the SRC circuit to by-pass
signals. Set to By-pass to output
asynchronous audio signals. To
embed the asynchronous audio
signals to SDI video signals, an audio
clock must be selected under (6-1-4)
“SDI AUDIO CLOCK“ for the
respective audio groups.
SRC IN:
Sets the SRC circuit to pass both PCM
or NON-PCM signals. Useful for the
irregular PCM signal with the
NON-PCM audio channel status
indication. However, real NON-PCM
signals cannot be output properly.
*1 If IN SEL in section 5-7-1 “VIDEO INPUT SET“ is set to SDI 1 or SDI 2, the embedded
audio signals of either selected SDI 1 or SDI 2 will be assigned to SDI 1/2 – 15/16. If IN
SET is set to other than SDI 1 and SDI2 such as COMPOSITE, the embedded audio
signals of SDI 1 input video will be assigned.
*2 If the AES connector is set to be used for output, the menu display for the selected AES
audio channel pairs appear as *AES1/2. See section 6-2-5 “AES I/O SETUP” and change
the setting if necessary.
NOTE
The 16 audio channels can be set to output from desired output connectors or embed
into SDI signals. See section 6-1-2 “SDI REMAPPING” for how to embed the audio
channels into SDI signals.
The SDI embedded audio signals can be masked on a group basis. See sections
5-10-11 “CONV1 AUDIO GROUP” and 5-10-12 “CONV2 AUDIO GROUP” for details.
For details on AES output, see section 6-2-3 “AES REMAPPING”. For analog output,
see section 6-3-5 “ANALOG REMAPPING”.
