9-3-5. Audio Output Delay
Clicking block (5) on the audio block diagram opens the Audio Delay dialog box.
After completing the settings, click Close to close the dialog box.
Click Refresh to update the settings.
Click Unity to reset to the default settings.
Click to increase the value by the smallest steps.
Click to decrease the value by the smallest steps.
Parameter Default Setting range Description
Audio Output
Delay
16msec
Master 2 - 1000msec
Sets the delay for
SOURCE channels.
CH1-16 2 - 1000msec
*1
*1 The total value of Master and individual channel cannot exceed the setting range. The
setting value will stop at the end of the range.
Enabling Delay Adjust under Video Sub in the 9-4-1 “ Video System“ while CONV1 or
CONV2 is in use adds a delay equivalant to 1 frame (2 frames for progressive signals) of
the input video signal to the set value. The maximum delay in such cases will be
{1,000msec + 1 frame (2frames for progressive signals) of the input video signal}.
+
-
