5-4-4. CONV2 CROPPING
CONV2 CROPPING 23
LEFT : 0PIXEL
RIGHT : 0PIXEL
TOP : 0LINE
BOTTOM: 0LINE
Parameter Default
Setting range
(Steps)
Description
LEFT 0 Pixel
Variable
*1
(2 Pixel)
Crops the left side of the video.
RIGHT 0 Pixel
Variable
*1
(2 Pixel)
Crops the right side of the video.
TOP 0 Line
Variable
*1
(1 Line)
Crops the top of the video.
BOTTOM 0 Line
Variable
*1
(1 Line)
Crops the bottom of the video.
These setting ranges vary depending on the input signal. LEFT and RIGHT settings, and the
TOP and BOTTOM settings interact with each other. If the size cannot be adjusted as desired,
try changing the setting of another parameter.
*1 The following parameters interact with each other. When you change one of their setting
values, setting ranges of other parameters will also change.
Input video format
SYNC FRMT Parameter in FS MODE SET (see section 5-10-1).
If the CONV2 mode is set to BY-PASS, the CONV2 CROPPING setting cannot be changed.
Also, it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in
the CONV2 Conversion Table (see section 5-4-2). In both cases, the menu as shown below
will be displayed.
CONV2 CROPPING 23
LEFT :NOT ADJUST
RIGHT :NOT ADJUST
TOP :NOT ADJUST
BOTTOM:NOT ADJUST
IMPORTANT
The cropping setting range resets itself if the video input changes. If the set value
exceeds the setting range due to an input change, the set value will automatically
reset itself to the default value. If the set value exceeds the horizontal range, the LEFT
and RIGHT settings will reset to their default values. If the value exceeds the vertical
range, the TOP and BOTTOM settings will also reset accordingly.
