79
5-11. NTSC SETUP
This menu, which allows you to set the analog composite, Y/Pb/Pr, or Y/C NTSC input and
output signal settings, is accessible only if the FA-95AIO option is installed.
NTSC SETUP 114
NTSC SETUP:ON
Parameter Default Setting range Description
NTSC SETUP OFF
OFF
ON
Set to OFF for signals without 7.5 IRE setup.
Set to ON for signals with 7.5 IRE setup.
5-12. PAL-M MODE SET
Allows PAL-M signals to be output from the COMPOSITE OUT and Y/C
*1
connectors.
PAL-M MODE SET 115
MODE:DISABLE
Parameter Default Setting range Description
MODE DISABLE
DISABLE
ENABLE
DISABLE: Allows NTSC signals to be output.
ENABLE: Allows PAL-M signals to be output.
*2
*1 Y/C output is supported only if the FA-95AIO option is installed and Y/C output is selected.
*2 This setting enables PAL-M output for COMPOSITE OUT and Y/C
*1
outputs, however,
NTSC signal output will be disabled.
To synchronize the PAL-M output, input a PAL-M BB or 59.94/29.97 Hz tri-level sync
signal to the GENLOCK IN connector. (NTSC BB signals cannot synchronize PAL-M
output signals.)
PAL signals can always be input and output regardless of this setting.
Menu button
VIDEO SYS
AUDIO SYS
Menu button
VIDEO SYS
AUDIO SYS
