5-10-10. CONV2 ANC SET
CONV2 ANC SET 100
ANC MODE:H/V ANC
H ANC:OVERWRITE
V ANC:BLANK
Parameter Default Setting range Description
ANC
MODE
H/V ANC
H/V ANC
DETAIL
Selects ancillary data processing mode for the
CONV2 output signal. H ANC and V ANC menu
settings will become available when H/V ANC is
selected.
DETAIL: Removes all H and V ancillary data,
and embeds newly specified ancillary data
(such as CC and AFD).
Set to DETAIL to enable settings in 5-10-16.
“ANC DATA EMBED” and 5-10-17. “ANC
EMBED LINE”.
H ANC * OVERWRITE
OVERWRITE
IN DATA
BLANK
Embeds audio signals into horizontal ancillary
data of CONV2 output videos.
OVERWRITE: Removes the embedded audio
signal from the input SDI video signal, then
embeds the processed audio data on the video
signal. Whether to embed is determined by the
AUDIO GROUP setting in section 5-10-12
“CONV2 AUDIO GROUP”.
The input SDI data will be embedded on the
video signal after audio signals are embedded.
IN DATA: Passes the input SDI horizontal
ancillary data without processing. (Processed
audio data cannot be embedded.)
BLANK: Deletes all horizontal ancillary data,
and embeds the processed audio data.
V ANC * PASS
PASS
BLANK
Embeds audio signals into vertical ancillary data
of CONV2 output videos.
PASS: Embeds the vertical ancillary data
without processing.
BLANK: Deletes all vertical ancillary data.
* H ANC and V ANC settings become available when ANC MODE is set to H/V ANC. H ANC
and V ANC settings are effective if input and output formats are the same. If such formats
are different, both H ANC and V ANC will be set to BLANK.
