6-9-7. Dolby ENCODER SETTING
* Menu is available only if the FA-95DE-E option is installed.
Dolby ENC SET 307
PROGRAM : 5.1+2
BIT DEPTH:20bit
FRAME REF:CONV1
Parameter Default Setting range Description
PROGRAM 5.1+2
5.1+2
*1
5.1+2x1
*1
4+4
*1
4+2x2
*1
4+2+2x1
*1
4+4x1
*1
4x2
*1
3x2+2x1
*1
2x2+4x1
*1
2+6x1
*1
8x1
*1
5.1
4+2
4+2x1
3x2
2x2+2x1
2+4x1
6x1
4
2+2
2+2x1
4x1
7.1
*1
7.1 Screen
*1
Selects Dolby E encoder program
configuration.
See Dolby E Encoder Input Channel
Assignment table in section 13 “Dolby
E Decoder/Encoder Channel
Assignment Table” for channel
assignments of respective
configurations.
BIT DEPTH 20bit
20bit
16bit
Selects the bit width of the Dolby E
encoder output.
FRAME REF CONV1
CONV1
CONV2
Selects a video output to which the
Dolby E encoder output is
synchronized. (Converter 1 or
converter 2)
*2
*1 If BIT DEPTH is set to 16bit, the “＊“ will be displayed and the program functions as 5.1. To
select these configurations, set BIT DEPTH to 20bit.
*2 See section 5-8 “VIDEO OUT SELECT (OUT SEL)” for details on CONV1 and CONV2
settings.
6-9-8. METADATA INPUT
* Menu is available only if the FA-95DE-E option is installed.
METADATA INPUT 308
SELECT : INTERNAL
Parameter Default Setting range Description
SELECT INTERNAL
INTERNAL
Dolby DEC OUT
Selects a metadata to be used for Dolby E
encoding.
INTERNAL: Uses the program
configuration and bit depth selected in the
6-9-7 Dolby ENCODER SETTING menu.
Other metadata will be reset to default.
Dolby DEC OUT: Uses the metadata of the
Dolby E signal input to the Dolby decoder.
The program configuration and bit depth
selected in the 6-9-7 Dolby ENCODER
SETTING will be ineffective.
