62
5-9-1-4. CONV2 KEYER SET
Allows you to set a keyer for CONVERTER 2.
CONV2 KEYER SET 404
KEYER:OFF
LEVEL:100%
H POS: 0PIXEL
V POS: 0LINE
Parameter Default
Setting range
(Steps)
Description
KEYER OFF
OFF
ON
Allows you to enable or disable the keyer for
the Converter 2 output signal.
ON: Enables to display logos selected in the
5-9-1-3 CONV2 LOGO SEL menu.
LEVEL
*1
100%
0-100%
(0.1%)
Allows you to set a key level for a logo to be
output to the Converter 2 output signal.
H POS
*1
0
*2
(2 Pixel)
Allows you to set the horizontal positon for a
logo to be output to the Converter 2 output
signal.
V POS
*1
0
*2
(1 Line)
Allows you to set the vertical positon for a
logo to be output to the Converter 2 output
signal.
*1 Key level and position settings are saved for each logo ID. Changing logo settings for
Converter 2 will also change the logo settings of Converter 1 using the same logo.
*2 Actual logo position differs depending on the logo format selected when registering the
logo. See section 5-9-1-5 “Logo Position Setting Range” for details.
LEVEL and H/V POS settings are disabled under the following conditions:
No logo is assigned to the logo ID selected under LOGO ID in the 5-9-1-3 CONV2
LOGO SEL menu.
Different formats are displayed for LOGO FORMAT and CONV2 in the 5-9-1-3
CONV2 LOGO SEL menu.
CONV2 KEYER SET 404
KEYER:ON
LEVEL:NOT ADJ
H POS:NOT ADJ
V POS:NOT ADJ
5-9-1-5. Logo Position Setting Range
Positional settings will vary according to the logo formats as shown below.
Logo Format H POS setting range V POS setting range
SD 525 0 to 718 0 to 486
SD 625 0 to 718 0 to 575
HD 1080 0 to 1918 0 to 1079
HD 720 0 to 1278 0 to 719
The logo format selection is saved for each logo ID using FA-95LG GUI. See the separate
FA-95LG GUI Operation Manual for details.
