FOR-A FA-9500 - Conv1 Anc Out1; Conv2 Anc out; Conv2 S2016 out

94
5-17. CONV1 ANC OUT1
CONV1 ANC OUT1 675
S334-1 CEA608 L 11
L indicates the line number into which ancillary data is inserted.
Displays the ancillary data packet name and line number for the inserted ancillary data in the
CONV 1 output signal. The status of up to 4 ancillary data can be displayed.
See section 19. “FA-9500 Ancillary Data Packet Name List” for details on ancillary data names.
5-18. CONV2 ANC OUT
CONV2 ANC OUT 681
CEA608:PRESENT L: 21
WSS:ABSENT
VI:PRESENT L:14/277
Displays the status of CEA608, WSS, and VI ancillary data inserted into luminance signal of the
CONV 2 output.
The line number in which the ancillary data is in is displayed.
Displays PRESENT if ancillary data is inserted. Displays ABSENT if no anceillary data is inserted.
If ANC MODE is set to H/V ANC, the state of the V ANC setting (PASS or BLANK) will be
displayed. In such case, no line number will be displayed. (See section 5-10-10 CONV2 ANC
SET for details on ANC MODE and V ANC setting.)
5-18-1. CONV2 S2016 OUT
Displays whether the S2016-3 ancillary data is inserted into CONV 2 output video signal.
 When no S2016-3 is in the CONV2 output video signal
CONV2 S2016 OUT 682
S2016-3:ABSENT
If ANC MODE in 5-10-10 CONV2 ANC SET is set to H/V ANC, the state of the V ANC setting
(PASS or BLANK) is displayed.
 When S2016-3 is in the CONV2 output video signal
CONV2 S2016 OUT 682
S2016-3:PRESENT
AFD:02 AR:0
4:3 L 16:9T
D:10000000 00000000
AFD: Active Format Description is displayed in hexadecimal format.
AR: Aspect Ratio is displayed in binary format (0=4:3, 1=16:9)
The detected AFD type is shown on the third row.
D: Detected Data1-8 are displayed in hexadecimal format.


See section 20-6 “AFD Code Abbreviations” for details on AFD types.
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
Menu button
STATUS
OTHER
