6-9-2. Dolby DECODER INPUT
* This menu is available only if the FA-95D-D option is installed.
Dolby DEC INPUT 302
INPUT :AUX IN
STREAM:LOSS
PROGRAM:LOSS
Parameter Default Setting range Description
INPUT AUX IN
AUX IN
SOURCE 1/2 -15/16
Selects an audio signal to be input to the
Dolby decoder.
AUX IN: Input signal in the optional Dolby
input connector (Dolby IN).
SOURCE 1/2 – 15/16: SOURCE signals
selected in the 6-5 AUDIO MAPPING
(MAPPING) menu.
STREAM -
D 32bit
D 16bit 1CH
D 16bit 2CH
D 16bit 1/2CH
E 24bit
E 20bit
E 16bit
PCM
LOSS
ERROR
Displays signal type and bit width of signal
selected under INPUT.
D ***: Dolby Digital signal
E ***: Dolby E signal
PCM: Normal audio signal
LOSS: No signal
ERROR: Unidentifiable
PROGRAM -
Dolby E
5.1+2
5.1+2x1
4+4
4+2x2
4+2+2x1
4+4x1
4x2
3x2+2x1
2x2+4x1
2+6x1
8x1
5.1
4+2
4+2x1
3x2
2x2+2x1
2+4x1
6x1
4
2+2
2+2x1
4x1
7.1
7.1 Screen
NON-Dolby E
Displays Dolby E program configuration
(Coding mode) or status of signal selected
under INPUT.
See Dolby E/Digital Decoder Output
Channel Assignment table in section 13
“Dolby E Decoder/Encoder Channel
Assignment Table” for channel
assignments of respective configurations.
Dolby Digital
1+1
1/0
2/0
3/0
2/1
3/1
2/2
3/2
3/0L
2/1L
3/1L
2/2L
3/2L
LOSS
INVALID
