5-4. CONV2 (UP / DOWN / CROSS CONVERTER)
The video signal selected under IN SEL in the VIDEO INPUT SELECT (IN SEL) menu as shown
in section 5-7 will be input to UP/DOWN CONVERTER2 (CONV2). The signal will be processed
in CONV2 and output from the output connector for which CONV2 is selected under ASSIGN in
the “VIDEO OUT SELECT (OUT SEL)” menu (Sec. 5-8).
The converter requires 1 frame to process video signals, so that processed output signals are
delayed by 1 frame from the bypassed video signals. In case the input signal is a progressive
video signal, or all 3 following conditions are met, processed output signals will be delayed by 2
frames.
- SYNCHRO MODE is set to INPUT
- FRAME DELAY is set to OFF
- V phase settings for the Converter (CONV 1 or 2) are set between Minimum to 1 line
Change the settings, if necessary, referring to section 5-10-1 “FS MODE SET”, 5-10-6 “HD
PHASE SET” or 5-10-7 “SD PHASE SET”.
