64
*7 Switching input signals with a phase difference using a router or such device may cause
shock noise to occur on video or audio signals if the phase difference (compared to the
genlock signal) exceeds the range shown in the following table. If the difference is within
range, shock noise will not occur.
Video format Phase difference from genlock signal
SD -1H (with line differences depending on video format) to +1/2H
HD -5H (with line differences depending on video format) to +1/2H
Table of Reference signals and Input formats that can lock
Reference signal
Input signal 525/60 1080/59i 720/59p 625/50 1080/50i 720/50p 1080/23PsF 1080/24PsF
525/60 ✓✓✓ ✓✓✓ ✓ - - - ✓ -
1080/59i ✓✓✓ ✓✓✓ ✓ - - - ✓ -
720/59p ✓✓✓ ✓✓✓ ✓✓✓ - - - ✓ -
1080/59p ✓✓✓ ✓✓✓ ✓✓✓ - - - ✓ -
625/50 - - - ✓✓✓ ✓✓✓ ✓ - ✓
1080/50i - - - ✓✓✓ ✓✓✓ ✓ - ✓
720/50p - - - ✓✓✓ ✓✓✓ ✓✓✓ - ✓
1080/50p - - - ✓✓✓ ✓✓✓ ✓✓✓ - ✓
1080/23PsF ✓ ✓ ✓ - - - ✓✓✓ -
1080/24PsF - - - ✓ ✓ ✓ - ✓✓✓
✓✓✓: SYNCHRO can be set to FRAME, LINE, or AVDL.
✓: SYNCHRO can only be set to FRAME.
-: Unable to synchronize.
*8 If an FA-95CO option is installed and TRIGGER is set to ENABLE in 5-7-6. FORMAT
ERROR TRG, a change cannot be made.
5-10-2. FREEZE SET
Allows you to set an operation mode for FREEZE.
FREEZE SET 92
FREEZE:OFF
MODE :FRAME
STROBE： OFF
Parameter Default Setting range Description
FREEZE
*1
OFF OFF, ON Turns FREEZE ON/OFF.
MODE
*2
FRAME
FRAME
ODD, EVEN
Select an operation mode for FREEZE.
STROBE OFF
OFF
1 - 255
Sets the interval to refresh the images by the
number of fields for the field or frame freeze.
OFF: Images are not refreshed.
*1 Changing the SYNCHRO setting in section 5-10-1 “FS MODE SET” while FREEZE is set
to ON will turn FREEZE OFF. FREEZE cannot be set to ON if SYNCHRO is set to LINE or
AVDL. FREEZE is always set to OFF at startup. These settings are not stored in the event
memory.
FREEZE SET 92
FREEZE:NOT ADJUST
MODE :NOT ADJUST
STROBE:NOT ADJUST
FS MODE IS NOT FRAME
When FREEZE is ON: button flashes.
Menu button
VIDEO SYS
AUDIO SYS
VIDEO SYS
AUDIO SYS
