6-3. ANALOG AUDIO Settings (ANALOG)
6-3-1. ANALOG IN LEVEL
ANALOG IN LEVEL 141
CH SEL :CH1
LEVEL SET: +4dBm
Parameter Default Setting range Description
CH SEL CH1 CH1 - CH4
Selects an analog audio input
channel for which to set the signal
level from channels CH1 to CH4.
LEVEL SET +4dBm
-10dBm
0dBm
+4dBm
+8dBm
Sets the signal level for the analog
audio input signal that is selected
under CH SEL.
6-3-2. ANALOG IN GAIN
ANALOG IN GAIN 142
CH SEL :CH1
GAIN SET:0.0dB
MASTER :0.0dB
Parameter Default
Setting range
(Steps)
Description
CH SEL
CH1 CH1 - CH4
Selects an analog audio input
channel for which to set the input
gain from channels CH1 to CH4.
GAIN SET 0.0dB
-20.0 - +20.0 dB
(0.1 dB)
*1
Sets the input gain for the analog
audio input signal that is selected
under CH SEL.
MASTER 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to the input gain for
all analog audio channels CH1 to
CH4.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0dB or *-20.0dB.
6-3-3. ANALOG OUT LEVEL
ANALOG OUT LEVEL 143
CH SEL :CH1
LEVEL SET: +4dBm
Parameter Default Setting range Description
CH SEL CH1 CH1 - CH4
Selects an analog audio output
channel for which to set the signal
level from channels CH1 to CH4.
LEVEL SET +4dBm
-10dBm
0dBm
+4dBm
+8dBm
Sets the signal level for the analog
audio output signal that is selected
under CH SEL.
