*2 If the input signal is a PsF signal, MODE is automatically set to FRAME and the setting
cannot be changed. See the following FREEZE MODE table for details.
FREEZE Mode Table
Input signal
SYS FRMT setting 525/60 625/50 1080/59i 1080/50i 720/59p 720/50p 1080/23PsF 1080/24PsF 1080/59p 1080/50p
AUTO OE OE OE OE F F F F F F
525/60 OE NOE NOE NOE NOE NOE NOE NOE NOE NOE
625/50 NOE OE NOE NOE NOE NOE NOE NOE NOE NOE
1080/59i NOE NOE OE NOE NOE NOE NOE NOE NOE NOE
1080/50i NOE NOE NOE OE NOE NOE NOE NOE NOE NOE
720/59p NF NF NF NF F NF NF NF NF NF
720/50p NF NF NF NF NF F NF NF NF NF
1080/23PsF NF NF NF NF NF NF F NF NF NF
1080/24PsF NF NF NF NF NF NF NF F NF NF
1080/59p NF NF NF NF NF NF NF NF F NF
1080/50p NF NF NF NF NF NF NF NF NF F
OE: Can be set to FRAME, ODD, or EVEN.
F: Fixed to FRAME.
NOE: Can be set to FRAME, ODD, or EVEN, but the image does not appear properly.
NF: Fixed to FRAME, and the image does not appear properly.
See section 5-10-1 “FS MODE SET” for the SYS FRMT.
5-10-3. COMPOSITE SET
COMPOSITE SET 93
COMB FILTER:3D
NR LEVEL :OFF
CROSS COLOR:OFF
NTSC SETUP :OFF
Parameter Default Setting range Description
COMB FILTER 2D
3D
2D
TRAP
Selects a mode to separate the Y
(luminance) and C (chrominance) of
composite signals.
NR LEVEL OFF
OFF
LEVEL1 - 4
Sets the noise reduction level for the
composite signal inputs.
CROSS COLOR OFF
OFF
LEVEL1 - 3
Sets the cross color (noise) reduction
level.
NTSC SETUP
*1
OFF
OFF
ON
Select OFF when using signals without 7.5
IRE setup.
Select ON when using signals with 7.5 IRE
setup.
*1 This parameter will not be displayed when the FA-95AIO option is installed. It is supported
in the NTSC SETUP menu (section 5-15).
