5-13-16. AFD IN STATUS
When detecting AFD in input S2016-3
AFD IN STATUS 641
DETECT:S2016-3
AFD:02 AR:0
4:3 L 16:9 T
D:10000000 00000000
AFD: Active Format Description is displayed in hexadecimal format.
AR: Aspect Ratio is displayed in binary format (0=4:3, 1=16:9)
The detected AFD type is shown on the third row.
D: Detected Data1-8 are displayed in hexadecimal format.
When detecting AFD in input RP186 VI
AFD IN STATUS 641
DETECT： RP186 VI
AFD： 02 SS： 00
4:3 L 16:9 T
D1： 10 D2： 00 D3： 00
Displays the status of RP186 VI (Video Index) Class1.
AFD: Active Format Description is displayed in hexadecimal format.
SS: Scanning System is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
D1-D3: Detected Data are displayed in hexadecimal format.
When detecting AFD in input BT1119-2 WSS
AFD IN STATUS 641
DETECT： BT1119 WSS
AFD:01
BOX 14:9 CENTER
BIT13-0:0000
Displays the status of BT1119-2 WSS (Wide Screen Signalling).
AFD: Active Format Description is displayed in hexadecimal format.
The detected AFD type is shown on the third row.
BIT13-0: Detected Bits 13 – 0 are displayed in hexadecimal format.
See section 20-6 “AFD Code Abbreviations” for details on AFD types.
5-14. ANC IN STATUS
ANC IN STATUS 651
CEA608:PRESENT L: 21
WSS:ABSENT
VI:PRESENT L:14/277
Displays the status of CEA608, WSS, and VI ancillary data in the input signal luminance
component.
The line number in which the ancillary data is in is displayed.
