107
6-3-4. ANALOG OUT GAIN
ANALOG OUT GAIN 144
CH SEL :CH 1
GAIN SET :0.0dB
MASTER :0.0dB
Parameter Default
Setting range
(Steps)
Description
CH SEL CH1 CH1 - CH4
Selects an analog audio output
channel for which to set the input
gain from channels CH1 to CH4.
GAIN SET 0.0dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the output gain for the analog
audio output signal that is selected
under CH SEL.
MASTER 0.0 dB
-20.0 - +20.0 dB
(0.1 dB)
Sets the offset to the output gain
for all analog audio channels CH1
to CH4.
*1 The total value of GAIN SET and MASTER should not exceed the setting range. If the
range is exceeded, the alert will be displayed as *20.0dB or *-20.0dB.
6-3-5. ANALOG REMAPPING
ANALOG REMAPPING 145
CH SEL:ANALOG1
ASSIGN:SOURCE1
SOURCE:SDI1
Parameter Default Setting range Description
CH SEL ANALOG1 ANALOG1 - 4
Selects an analog audio output channel
from ANALOG1 through 4.
ASSIGN
Each
SOURCE
SOURCE1 – 16
*1
500Hz
1KHz
SILENCE
DOWNMIX-L
*2
DOWNMIX-R
*2
Dolby DEC1 – 8
*3 *5
Dolby DM-L
*4 *5
Dolby DM-R
*4 *5
Selects a signal f to output from the
analog audio output channel that is
selected under CH SEL.
SOURCE 1-16: Signals assigned to
SOURCE channels
500Hz/1KHz: Test signal
SILENCE: Mute signal
DOWNMIX-L/R: Downmixed signal
generated from SOURCE channels.
Dolby DEC 1-8: Dolby-decoded PCM
signals
Dolby DM-L/R: Downmixed signal
generated from Dolby-decoded PCM
signals
SOURCE -
SDI1 - 16
AES1 - 8
ANA1 - 4
Displays the input signal in the SOURCE
channel selected under ASSIGN. Shown
only if ASSIGN is set to SOURCE 1-16.
*1 See section 6-5 “AUDIO MAPPING (MAPPING)” for detail on SOURCE settings.
*2 See section 6-7 “DOWN MIX SET” for details on DOWN MIX settings.
*3 See section 6-9-2 “Dolby DECODER INPUT” for details on Dolby DEC settings.
*4 See section 6-9-4 “Dolby DOWNMIX” for details on Dolby DM settings.
*5 Shown only if FA-95D-D option is installed.
Menu button
CONV1
ANALOG
Menu button
CONV1
ANALOG
