20
5-2-2. BLACK LEVEL
BLACK LEVEL 3
RED : 100.0%
GREEN: 100.0%
BLUE : 100.0%
GROUP ADJUST
Parameter Default
Setting
range
(Steps)
Description
RED, GREEN, BLUE
(RGB Black Level)
100.0%
0.0 - 200.0%
(0.5%)
Adjusts the black level of R, G, and B
components separately.
GROUP ADJUST
(Group Adjustment)
100.0%
0.0 - 200.0%
(0.5%)
Adjusts the black level of R, G, and B
components all together while
retaining the proportion of the
separately adjusted levels.
If MODE is set to SEPIA in the COLOR CORRECT (C.C.) menu (5-2-4), the menu as shown
below will be displayed.
BLACK LEVEL 3
RED :NOT ADJUST
GREEN:NOT ADJUST
BLUE :NOT ADJUST
C.C MODE IS SEPIA *1
*1 If AVO is enabled, the message “AVO IS USING IT” will be displayed.
5-2-3. GAMMA LEVEL
GAMMA LEVEL 4
RED : 100.0%
GREEN: 100.0%
BLUE : 100.0%
GROUP ADJUST
Parameter Default
Setting range
(Steps)
Description
RED, GREEN, BLUE
(RGB Gamma level)
100.0%
0 - 200%
(0.5%)
Adjusts the gamma level of R, G,
and B components separately.
GROUP ADJUST
(Group Adjustment)
100.0%
0 - 200%
(0.5%)
Adjusts the gamma level of R, G,
and B components all together while
retaining the proportion of the
separately adjusted levels.
If MODE is set to SEPIA in the COLOR CORRECT (C.C.) menu (5-2-4), the menu as shown
below will be displayed.
Only the value of GREEN can be changed.
GAMMA LEVEL 4
SEPIA:100.0%
The menu appears as shown below if AVO is enabled.
GAMMA LEVEL 4
RED :NOT ADJUST
GREEN:NOT ADJUST
BLUE :NOT ADJUST
AVO IS USING IT
